FOXY VOLTAGE REGULATOR 6A UBEC (21515)

Foxy UBEC 6A is a classic voltage regulator that converts 7.4-25V into 5 or 6V (regulated with a jumper) to power the receiver and servos. For use in models of airplanes, helicopters, cars and boats with internal combustion or electric drive. Built-in diodes show the current operating voltage (5 / 5.5 or 6V), the system is protected against reverse polarity.

Technical data:

• power supply: 6-25V (5-18 Ni-xx, 2-6S Li-pol)
• output voltage: 5 or 6V, switchable with a jumper
• output current: 6A (temporary: 10A)
• dimensions: 45x23x10 mm.
• weight: 18 g.

The instruction in Polish, developed by Mr. Ludomir Rogalski, can be found here : instructions

The instructions and connection diagram in Czech can be found here
