TRAXXAS E-MAX 4WD TSM Z NAPĘDEM BEZSZCZ. 1/10 4WD (39087)

Before buying a model, read the warranty and operation rules.
The file is available for download in the "Attachments" tab.

E-Maxx 4X4 with Castle MXL 6s drive, TSM system and telemetry sensors

• New traction control system "Traxxas Stability Management ™"
• TQi 2.4GHz "Traxxas Link Wireless Module" radio system
• Factory installed - Castle MXL-6s brushless drive unit
• High power 2200Kv brushless motor
• Two NiMh 8.4V / 3000mAh drive packages included
• 4A quick charger

E-Maxx driveline.

The drive system was built for the needs of one of the most powerful drives based on a brushless motor powered by 6 LiPo packets. Such a powerful drive is the best recipe for self-destruction of the car structure, and the occurring extreme forces are a real challenge for the constructor. The possibility of powering with two 11.1V LiPo packets uses the drive and the entire structure to the maximum, bringing this monster to a speed of over 100 km / h.

MXL-6s Brushless Power System Castle.

It is one of the most powerful propulsion systems based on power packets consisting of six cells.
The MXL-6s regulator is equipped with gold-plated connectors with a diameter of 6.5 mm in order to transfer extremely high currents and high efficiency heat sink, additionally cooled by an integral fan.
The 2200kV / 75mm brushless motor is made of aluminum in the form of a huge heat sink that can withstand extremely high currents. The motor is based on neodymium magnets, high-quality bearings, and the torque is transmitted by a 5-millimeter shaft.

Table of selection of drive packages depending on the expected performance of the model.

Total Control.

Traxxas models deserve the most advanced - race-ready radio system. After all, this is the only connection between the driver and the machine. The system must be precise, comfortable and reliable. The all-new Traxxas ® TQi ™ radio system does all of this, plus it is both reliable and solidly built. The most important novelty of this system is the possibility of cooperation with the Traxxas Link App , available on the iPhone or iPod touch system . This creates a powerful tool for tuning the model. The color display connects to the Link Traxxas ™ system and creates an intuitive, high-definition - color graphical user interface that makes it possible to optimize the radio system for maximum vehicle control.

The transmitter is equipped with the Traxxas Link Wireless Module ™ , which provides wireless connectivity with devices running on Android or AppleiOS 4.4+ 4.3+ .

Traxxas Stability Management (TSM) - traction control.

The traction control system is built into the 5-channel TQI 2.4GHz Traxxas Link TSM receiver. Combined with the low center of gravity and traction control system, Slash takes on completely new handling characteristics.
Traxxas Stability Management (TSM) allows you to make the most of the full power, speed and acceleration of Slash 4X4 . Traction control is particularly effective when driving on slippery surfaces, smooth concrete, ice and snow. The TSM system corrects the trajectory when accelerating to ensure the full use of propulsion. TSM also works when cornering, making corrections to maintain your chosen line of travel. This allows you to maintain higher speed in the turn and faster exit from it. During braking, TSM keeps track until it comes to a stop.
In the traction control system, Traxxas has used the latest algorithms that run invisibly in the background, never restricting the throttle. The TSM can be individually tuned or completely turned off depending on the current road surface and its condition as well as the driver's preferences. The control over the system is ensured by a multifunctional knob mounted in the transmitter. The usefulness of Traxxas Stability Managemen is best demonstrated by turning the system off after an extended period of use.

Traxas Link app available on Google Play and App Store.

Traxxas Link App.

This powerful application gives you complete control over the functioning of your radio system. Now you have the option to install Traxxas telemetry sensors and App Link will display all data in real time: speed, engine RPM, pack voltage, motor temperature, power pack and regulator. Traxxas App Link is designed for use with Android 4.4 or Apple iOS 4.3+ .

Intuitive interface.

Traxxas Link collects and stores real-time telemetry data while driving. Traxxas Link dashboard shows speed, battery voltage, RPM and temperature. The app automatically detects and recognizes Traxxas Link sensors. The dashboard is fully customizable and can display the parameters of nine sensors simultaneously.
Once you have made the best settings for your model, you can save them as a profile that you can apply to another model later. If you make changes to your profile, you can save it as new. The Traxas Link app automatically detects telemetry sensors and is easy to install and configure.

Factory installed telemetry sensors.

E-Maxx is fully equipped with a set of telemetry sensors. They allow, using the Traxxas Link application, to record in real time such telemetry data as:

• speed
• voltage of drive packages
• engine speed
• engine temperature

­­

• New traction control system "Traxxas Stability Management ™"
• TQi 2.4GHz "Traxxas Link Wireless Module" radio system
• Factory installed - Castle MXL-6s brushless drive unit
• High power 2200Kv brushless motor
• Two NiMh 8.4V / 3000mAh drive packages included
• 4A quick charger
• Speed out of the box - 55 km / h , after tuning - 104 km / h
• New body painting "Prographix"
• Wheel mounting with 17mm Hex nut
• Aggressive - 6.3 inch tires on chrome rims

MODEL 39087 . Fully assembled, ready to go with TQi 2.4GHz Traxxas Link remote control , Castle MXL-6s drivetrain, painted ProGraphix ^® body. Comes with two 7-cell NiMh / 3000mAh Drive Packs.
