Savox Digital Servos

SAVOX SERWO SG-1213MG DIGITAL (4.5kg - 0.17s/60°) HiVolt 9.2mm

€50.00
13-1138
Savox
In stock

High-quality digital servo from the renowned Savox company.

Characteristics:

  • SSR compatible (allows ONLY in combination with SANWA RC kits like M-17, M-12S, M12RS, MT-44, MT-5 maximum speed and transmission precision)
  • SOFT START: Soft start (protects the servo and rudder control mechanism when the on-board electronics are on)
  • Aluminum housing: excellent heat dissipation

Servo especially recommended for gliders of the F3K category

Specifications:

  • Torque at 6 V - 3.5 kg
  • Torque at 7.4 V - 4.5 kg
  • Speed at 6 V - 0.21 s / 60 degrees
  • Speed at 7.4 V - 0.17 s / 60 degrees
  • operating voltage: 4.8 -m 8.7 V
  • Dimensions L x W x H (mm): 23 x 9.2 x 24.5
  • Bearings: 2xBB
  • Gear (gears): metal
  • Output gear: 21 teeth
  • Weight: 13.5 g
  • Working stroke: 90° (1000 → 2000 µs)
  • Neutral position: 1500 µs
  • Pulse width range: 750 → 2250 µs
  • Maximum travel: approximately 145° (750 → 2250 µs)
  • Refresh rate: 240 Hz
  • Motor type: coreless

*Follow the instruction manual included with the product.

Presentation of the servo in the video:
