Savox Digital Servos

SAVOX SERWO SV-0255MG+ DIGITAL (5kg-0.10s/60°) HiVolt

€25.71
13-1040
Savox
In stock

High-quality digital servo from the renowned Savox company.

Features:

  • SOFT START: Soft start (protects the servo and rudder control mechanism when the on-board electronics are on)

Specifications:

  • Torque at 6 V - 3.5 kg
  • Torque at 7.4 V - 4.5 kg
  • Torque at 8.4 V - 5.0 kg
  • Speed at 6 V - 0.16 s / 60 degrees
  • Speed at 7.4 V - 0.13 s / 60 degrees
  • Speed at 8.4 V - 0.10 s / 60 degrees
  • Dimensions L x W x H (mm): 22.8 x 12.0 x 29.4
  • Bearings: 1BB
  • Gear (gears): metal
  • Output gear: 21 teeth
  • Weight: 15.8 g
  • Operating range: 90° (1000 → 2000 µs)
  • Neutral position: 1500 µs
  • Pulse width range: 750 → 2200 µs
  • Maximum range: approximately 145° (750 → 2250 µs)
  • Refresh rate: 240 Hz
  • Motor type: DC (direct current)

*Follow the instruction manual included with the product
