DUALSKY REG.RPM 12A V2

A 12A, 15V speed controller from DUALSKY for 3-phase motors.

The regulator has firmware (software) version V.2 where:

• lINEAR BRAKE has been introduced
• the possibility of programming from a PC has been introduced; connection with a computer is possible thanks to the optional DUALSKY USB Link card
• the regulator on the package side is equipped with a JST connector, and on the motor side with DB3 connectors

Basic parameters:

• 12A continuous current (maximum momentary 18A)
• 2-3 Li-Ion/Li-pol cells (7.4-11.1V), 5-10 Ni-Cd/Ni-Mh cells (6.0-12.0V)
• BEC 5V/1A; (for 3 micro servos); for more servos it is recommended to use DUALSKY VR-3 voltage regulator
• motor handling: up to 210000 rpm (2-field), 70000 rpm (6-field) and 35000 rpm (12-field)
• programmable timing: normal, soft and super-soft
• programmable cut-off with setting: motor shutdown/power reduction
• programmable brake: on/off
• dimensions: 32×24.5×6 mm
• weight: 12g

*Follow the instructions included with the product.
