BLUE BIRD Digital Servos

BLUE BIRD Servo BMS-115WV+ (7.1kg - 0.09s/60°) Digital

€27.14
13-2061
BLUE BIRD
In stock

The BMS-115WV+ servo is a new version of the BMS-115HV servo . The parameters have been improved, and ball bearings have been added. The servos are equipped with vertical flanges for easy installation in wings. Recommended for use in 3D EP aircraft, the F3K, F3P and DLG and HLG categories. The servos are also suitable for installation in F5J size models.

The output shaft has a 25-tooth drive lever with a diameter of 6 mm, identical to Futaba servos. This makes replacing the lever very easy. The connection between the shaft and the lever is very rigid and backlash-free.

Technical data:

  • torque [kg-cm]: 3.7V: 3.6 / 6.0V: 5.5 / 7.4V: 6.6 / 8.4V:7.1
  • speed [sec]: 3.7V: 0.20 / 6.0V: 0.13 / 7.4V: 0.10 / 8.4V: 0.09
  • weight: 11g +/- 0.5
  • gearbox: metal
  • motor: coreless
  • operating frequency: 333 Hz
  • standstill zone: 0.002 ms
  • digital: yes
  • programmable: no
  • included: levers

For more information and photos, visit the manufacturer's website : TU

*Follow the instruction manual included with the product.
